Feedrate |
Rapid traverse (X/Y/Z) |
30 / 30 / 30 |
Cutting feedrate |
1-15,000 |
Feed motor(X/Y/Z) |
4 /4 /7 |
Table |
Table Size |
1,700×660 |
Table surface |
22H8×p125×5ea |
Loading capacity |
1,300 |
ATC |
Tool Shank |
BT40(CAT40) |
Tooling changing method |
Double Arm Swing |
Tool Changing Time (T-T) |
1.2 |
Magazine Capacity |
30 |
Tool Selection |
Memory Random |
Max. Tool dia. (adjacent empty) |
Ø80[Ø125] |
Max. Tool Length / Weight |
300 / 7 |
Pull stud type |
MAS P40T-1 |
Motor |
Spindle drive motor(cont./30min) |
15 / 18.5 |
Travel |
Distance from table surface to spindle nose |
150~670 |
Spindle |
Spindle speed |
12,000 |
Torque (Cont. /Max.) |
69.6 / 117.8 |
Bearing inner diameter |
Ø70 |
Travels |
Y-axis travel |
670 |
X-axis travel |
1600 |
Z-axis travel |
520 |
Machine |
Req. floor space(L×W×H) |
4,105×3,400×3,000 |
Machine weight |
8,500 |
Electric power supply |
|
35 |
Controller |
|
Fanuc Series |
