Characteristics:
1.Table size: 1000x2000mm
2. X, Y, Z axes travel: 2000 x 1300 x 780mm
3. Spindle: NT50, 10HP/15HP
4. Spindle speed: 8 steps , 89-694rpm
5. Spindle stroke 300mm
6. Table milling motor 3kw
7. Driving by ball screw with servo motor for X axis
8. Y & Z axis driven by inverter
9. Horizontal beam by hydraulic
10. Splash cover for left/right side beam
11. Telescopic metal way cover for table
12. 6M working length is available (upon request)
