ITEM |
600T |
600 TY |
|
|
Standard |
C axis |
||
|
Swing over bed |
Ø600 mm |
Ø600 mm |
|
|
Swing over saddle |
Ø450 mm |
Ø450 mm |
|
|
Distance between center |
--- |
||
|
Max machining dia |
Ø380 mm |
Ø300 mm |
Ø220 mm |
|
Max machining length |
STD 360 mm(8”) OPT 345 mm (10”) |
STD 360mm(8”) OPT 345mm(10”) |
|
|
Distance between nose |
717 mm |
717 mm |
|
|
Sland angle of bed |
300 |
600 |
|
| TRAVEL | |||
| X travel |
195 mm |
205 mm |
168 mm |
| Y axis |
--- |
--- |
60(±30) |
| Z travel |
530 mm |
530 mm |
|
| C axis |
3600(0.0010) |
3600(0.0010) |
|
| W axis |
450 mm |
450 mm |
|
| SPINDLE | |||
| Spindle speed |
STD 50-4500 rpm (A2-6) OPT 50-3500 (A2-8) |
6000rpm(A2-5) |
|
| Spindle nose |
A2-6 |
A2-5 |
|
| Spindle bore diameter |
Ø62 OPT Ø86 |
Ø45 mm |
|
| Draw bar |
Ø75 OPT Ø75 |
Ø35 mm |
|
| Chuck diameter |
Ø8” OPT Ø10” |
W Ø6” |
|
| TURRET | |||
| Turret type |
Hydraulic |
Live tooling |
Live tooling |
|
Stations |
STD12 OPT10 |
12 OPT 8 |
12 OPT8 |
|
Square tool shank |
25x25 mm |
25x25mm |
|
|
Boring bar shank dia |
Ø40 mm |
Ø40 mm |
Ø40 mm |
|
Indexing time (0-180) |
1.7 s |
1.5 s |
1.5 s |
|
LIVE TOOLING |
|||
|
Spindle speed |
--- |
50-4000 rpm |
--- |
|
FEED RATE |
|||
|
Rapid traverse |
X16 Z20 W16 C200 m/min |
X16 Z20 Y8 C200 m/min |
|
|
TAILSTOCK |
|||
|
Type |
--- |
--- |
|
|
Quildia |
--- |
--- |
|
|
Quill bore taper |
--- |
--- |
|
|
Tailstock travel |
--- |
--- |
|
|
MOTORS |
|||
|
Main spindle |
11/15 KW |
11/15 KW |
|
|
Live tool |
--- |
3.7/5.5 Kw |
3.7/5.5Kw |
|
X/Z axis servo motor |
X: 3 Kw , Z 3 Kw ,W 3 Kw |
X: 3 Kw ,Y 3Kw, Z 3 Kw ,W 3 Kw |
|
|
Hydraulic oil pump |
1.5 Kw |
1.5 Kw |
|
|
Chip conveyor |
0.2 Kw |
0.2 Kw |
|
|
Coolant pump |
0.8 Kw |
0.8 Kw |
|
|
ACCURACY |
|||
|
Positioning |
±0.005 mm |
±0.005mm Y0.004 |
|
|
Repeatability |
±0.004 mm |
±0.004mm Y0.003 |
|
|
Packing dimension |
4020x2150x2510 mm |
4020x2150x2550 |
|
|
Net Weight |
6200 kg |
5990 kg |
|
