Technical data:
| Power supply | 220 - 240V / 50/60Hz | ||||||
| Drive | Condenser motor with 550W | ||||||
| Spindle driveX-axis | Recirculating ball spindle with 2.0mm inclination,flank diameter 8mm.Step motor with 1.8A and 50Ncm dwell moment;travel distance: approx. 70mm | ||||||
| Spindle drive Z-axis | Recirculating ball spindle with 4.0mm inclination,flank diameter 12mm.Step motor with 1.8A und 50Ncm dwell moment;travel distance: approx. 300mm | ||||||
| 6 spindle revolutions | 80 - 160 - 330 - 660 - 1,400 - 2,800/min .Selectable with switch (two-stage) and by placing drive belt. | ||||||
| Control of step motors | via CNC control unit (included in scope of delivery) | ||||||
| Software | on CD-ROM, installation under Windows 98, Windows 2000, Windows XP, Windows Vista and Windows 7 |
||||||
| Drive connection | via RS 232 interface (or: use of a USB adapter), connecting cables to PC included in scope of delivery | ||||||
| Sizes |
|
||||||
| Total weight | Machine: approx. 45kg / Control unit: approx. 4kg | ||||||
