Technical Data
| Main shaft taper | MT-2 |
| Main spindle motor | SERVO 0.75KW |
| Main spindle rotation speed | 3000RPM |
| Rotation diameter over bed | Ø150mm |
| Rotation diameter over carriage | Ø64mm |
| Distance Between Centers | 360mm |
| Min feed distance | 0.01mm |
| Feed distance(X,Z) | 110/200mm |
| Rapid feed speed | 6000mm/min |
| Feed Motor | AC SERVO 200W |
| Controller | SENTROL |
| Dimensions | 900x830x800 |
| Weight | About 100Kg |
